Sure-Fi SFK-DS006-RELAY Relay Wireless Bridge

Wire replacement for Relay Systems

• Installs in minutes

• Sure-as-a-wire Competitive with true cost of wiring for all job types (easy and diicult wire pulls)

• General purpose relays suitable for multiple applications

Specifications:

• 2 relay outputs (Wet or Dry)

• Battery backup input with battery charger and UPS function

• DIN rail mount or direct wall mount

• Signal Strength, Transmit & Receive indicators

• Test Button for easy range testing

• Field congurable and updatable with Sure-Fi® App

• OPERATING VOLTAGE: 12VDC +/- %5

• OPERATING CURRENT: 0.08A (idle), 0.75A (transmit)

• OPERATING POWER: 9 Watt (peak)

• TRANSMIT POWER: 1 Watt (30dBm)

• FREQUENCY BAND: 902 - 928Mhz

• CHANNELS: 72 (Frequency Hopping)

• RECEIVER SENSITIVITY: -133dBm

• LINK BUDGET: 163dB

• RANGE: Up to 1 mile through Obstructions. Greater than 40 Miles line-of-sight

• SECURITY ENCRYPTION: AES128

• BATTERY BACKUP CONNECTION: 12V Sealed Lead Acid (SLA) type

• BATTERY CHARGE VOLTAGE: 13.75V maximum at standby

• RELAYS: 2A 250VAC / 2A 250VDC

• Wet or Dry: NO, NC, COM OPERATING

• TEMPERATURE: -40oC to +85oC (-40oF to +185oF)

• STORAGE TEMPERATURE: -55oC to +125oC (-67oF to +257oF)

• MOUNTING OPTIONS: DIN 35 (35mm x 7.5mm) or directly mount with two screws
